The Firefighting Bomb Delivery System is a specialized emergency response payload developed exclusively for DJI delivery drone platforms. It integrates multi-sequence release, intelligent altitude-based airburst, and precision targeting into a single solution. Featuring a modular quick-release rotary design, the system can be fully mounted and deployed within 30 seconds. It comes standard with a 6-channel sequential electronic control mechanism, supporting flexible combinations of single-release, full-release, and other multi-mode operations, with a maximum single-hook payload capacity of up to 50 kg. Deeply adapted through DJI PSDK development, the system supports intelligent altitude measurement via the drone’s radar at 1–60 m, allowing airburst timing to be configured through the app. Each firefighting bomb provides a coverage area of ≥50 m². The system incorporates multiple safety protection features and anti-wireless interference design, and is compatible with dual missions including firefighting bomb delivery and emergency supply airdrop. Battle-tested in complex environments, it delivers a high-mobility, high-precision solution for high-rise firefighting, forest fire suppression, emergency rescue, and related scenarios.

Compatible Aircraft: FC30 / FC100 / FC200 / T70 / T70P / T100 / T100S

Product Specifications

For FC100

• Delivery System Dimensions: 480 mm × 260 mm × 145 mm (±5 mm)

• Delivery System Total Weight: 3 kg

• Mounting Method: Quick-release

• Operating Temperature: -20°C to 45°C

• Peak Power: ≤60 W

• ※ Maximum Payload: 80 kg on the two center hooks / 50 kg on perimeter hooks

• Standard Number of Hooks: 6

• ※ Release Method: Sequential electronic control, freely configurable as single-channel or multi-channel release in one operation

• ※ Airburst Altitude Information Source: Supports acquiring above-ground altitude from the aircraft’s onboard radar

• ※ Altitude Measurement Range: 30 m to 60 m

• Firefighting Bomb Communication Interface: 1–4 four-pin aviation sockets

• Safety Functions: Equipped with a safety switch; bomb status displayed on the remote controller

• ※ Communication Link: DJI UAV link

• Control Distance: Consistent with the UAV’s communication range

• Communication Interface: DJI FlyCart 100 E-Port Lite

• Power Supply Interface: FlyCart 100 aerial hoist system interface

• Control Method: PSDK

For FC200

• Delivery System Dimensions: 480 mm × 260 mm × 145 mm (±5 mm)

• Delivery System Total Weight: 3 kg

• Mounting Method: Quick-release

• Operating Temperature: -20°C to 45°C

• Peak Power: ≤60 W

• ※ Maximum Payload: 80 kg on the two center hooks / 50 kg on perimeter hooks

• Standard Number of Hooks: 6

• ※ Release Method: Sequential electronic control, freely configurable as single-channel or multi-channel release in one operation

• ※ Airburst Altitude Information Source: Supports acquiring above-ground altitude from the aircraft’s onboard radar

• ※ Altitude Measurement Range: 30 m to 60 m

• Firefighting Bomb Communication Interface: 1–4 four-pin aviation sockets

• Safety Functions: Equipped with a safety switch; bomb status displayed on the remote controller

• ※ Communication Link: DJI UAV link

• Control Distance: Consistent with the UAV’s communication range

• Communication Interface: DJI FlyCart 200 E-Port Lite

• Power Supply Interface: FlyCart 200 aerial hoist system interface

• Control Method: PSDK
