Designed for curtain wall cleaning, this drone-mounted spray kit delivers efficient, hassle-free operation with a modular build that installs or removes in under 3 minutes. The 30° wide-angle cross-swing spray system covers complex façade structures, while the lightweight 1.15kg payload ensures stable flight performance across a wide operating temperature range of –20°C to +45°C. With an open TCP protocol for secondary development and intuitive APP control, it makes high-altitude cleaning as simple as wiping a window.
Manual
Key Features
- Quick Installation: Modular design enables assembly or disassembly within 3 minutes.
- Wide Coverage: 30° cross-swing spray pattern effectively covers complex curtain wall structures.
- Ultra-Light Payload: 1.15kg design minimizes impact on drone flight performance.
- All-Weather Operation: Reliable operation from –20°C to +45°C.
- Open Protocol: TCP protocol supports secondary development for customized solutions.
- APP Control: Intuitive “Smart Payload” APP puts full control at your fingertips.
| Parameter |
Specification |
| Spray Gun Dimensions |
830 × 94 × 131 mm |
| Total Weight |
Approx. 1.15kg |
| Mounting Method |
Bolted connection |
| Mounting Position |
Underbelly of the drone |
| Control Method |
Smart Payload APP |
| Supply Voltage |
24V |
| Peak Power |
≤30W |
| Operating Temperature |
–20°C to +45°C |
| Spray Distance |
7–10m |
| Recommended Flight Altitude |
≤120m |
| Communication Interface |
Ethernet port |
| Spraying Method |
Cross-swing, left/right 60° |
| Spray Direction |
Forward / Left / Right |
| Hose Dimensions |
4mm ID × 8.6mm OD |
| Hose Pressure Rating |
20MPa |
